Will this fan be okay?

TomBerry

TomBerry

Bright Spark
Hello...again :)

Just gone and impulse bought a new RGB fan to swap out for my non-RGB black fan on the rear. Will this fan fit fine in terms of being able to connect it and have RGB working?

Corsair iCUE QL120 RGB, 120 mm RGB LED PWM Fan (34 Individually Addressable RGB LEDs, Speeds Up to 1,500 RPM, Low-Noise) Single Pack - Black: Amazon.co.uk: Computers & Accessories

Corsair iCUE QL120 RGB, 120 mm RGB LED PWM Fan (34 Individually Addressable RGB LEDs, Speeds Up to 1,500 RPM, Low-Noise) Single Pack - Black: Amazon.co.uk: Computers & Accessories
www.amazon.co.uk

Case is the LIAN LI LANCOOL II GAMING CASE and the motherboard is the ASUS® TUF Z490-PLUS GAMING (LGA1200, USB 3.2, CrossFireX) - RGB Ready

SpyderTracks

SpyderTracks

We love you Ukraine
TomBerry said:
Hello...again :)

Just gone and impulse bought a new RGB fan to swap out for my non-RGB black fan on the rear. Will this fan fit fine in terms of being able to connect it and have RGB working?

Corsair iCUE QL120 RGB, 120 mm RGB LED PWM Fan (34 Individually Addressable RGB LEDs, Speeds Up to 1,500 RPM, Low-Noise) Single Pack - Black: Amazon.co.uk: Computers & Accessories

Corsair iCUE QL120 RGB, 120 mm RGB LED PWM Fan (34 Individually Addressable RGB LEDs, Speeds Up to 1,500 RPM, Low-Noise) Single Pack - Black: Amazon.co.uk: Computers & Accessories
www.amazon.co.uk

Case is the LIAN LI LANCOOL II GAMING CASE and the motherboard is the ASUS® TUF Z490-PLUS GAMING (LGA1200, USB 3.2, CrossFireX) - RGB Ready
Click to expand...
To control it at all, you need a commander pro or a lighting node pro which is a little unit that all the fans connect to.

iCUE Commander PRO Smart RGB Lighting and Fan Speed Controller

The CORSAIR iCUE Commander PRO turns your PC’s case into a smart case, using CORSAIR iCUE software to power stunning RGB lighting customization, precise fan speed control and accurate temperature monitoring, all from a single device.
www.corsair.com www.corsair.com

iCUE Lighting Node PRO RGB Lighting Controller

The CORSAIR iCUE Lighting Node PRO RGB Lighting Controller brings stunning software-controlled RGB lighting to any PC, with four included RGB LED light strips boasting a total of 40 LEDs of RGB illumination.
www.corsair.com www.corsair.com

Normally you buy them in a pack of two or three fans and a lighting pro or commander pro, I would avoid the lighting core as it's just too basic and doesn't allow for any expansion:


Last edited:
TomBerry

TomBerry

Bright Spark
SpyderTracks said:
To control it at all, you need a commander pro or a lighting node pro which is a little unit that all the fans connect to.

iCUE Commander PRO Smart RGB Lighting and Fan Speed Controller

The CORSAIR iCUE Commander PRO turns your PC’s case into a smart case, using CORSAIR iCUE software to power stunning RGB lighting customization, precise fan speed control and accurate temperature monitoring, all from a single device.
www.corsair.com www.corsair.com

iCUE Lighting Node PRO RGB Lighting Controller

The CORSAIR iCUE Lighting Node PRO RGB Lighting Controller brings stunning software-controlled RGB lighting to any PC, with four included RGB LED light strips boasting a total of 40 LEDs of RGB illumination.
www.corsair.com www.corsair.com
Click to expand...

Thanks for that, just to clarify I can plug it in and the RGB will work, but I just can't control the lighting/speeds, or will the lighting not work at all?

SpyderTracks

SpyderTracks

We love you Ukraine
TomBerry said:
Thanks for that, just to clarify I can plug it in and the RGB will work, but I just can't control the lighting/speeds, or will the lighting not work at all?
Click to expand...
The lighting wouldn’t work at all because you’d have nowhere to plug it in.

TomBerry

TomBerry

Bright Spark
SpyderTracks said:
The lighting wouldn’t work at all because you’d have nowhere to plug it in.
Click to expand...
Hm, understandable 🤔 So I'm assuming I can't just buy a singular RGB fan that I can connect to the motherboard and have working like the fan I have in now?

TomBerry

TomBerry

Bright Spark
SpyderTracks said:
They all need a controller.
Click to expand...

Just gone with this instead then, only cheap but I want pretty colours

ICETEK RGB Case Fans 3 Pack, ARGB 120mm Silent Computer LED Fan Music Rhythm Cooling PC Fans, 5V Addressable Motherboard SYNC/RC Controller, Colorful Cooler Speed Adjustable with Fan Control Hub: Amazon.co.uk: Computers & Accessories

Buy
www.amazon.co.uk


Scott

Scott

Behold The Ford Mondeo
Moderator
If the motherboard has a spare ARGB header, would that not control it?

SpyderTracks

SpyderTracks

We love you Ukraine
Scott said:
If the motherboard has a spare ARGB header, would that not control it?
Click to expand...
On the motherboard manual it states this under the RGB headers:

The Addressable Gen2 header supports WS2812B addressable RGB LED strips (5V/ Data/Ground), with a maximum power rating of 3A (5V), and the addressable headers on this board can handle a combined maximum of 500 LEDs.
Before you install or remove any component, ensure that the power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.
• •
• •
Actual lighting and color will vary with LED strip.
If your LED strip does not light up, check if the addressable RGB LED strip is connected in the correct orientation, and the 5V connector is aligned with the 5V header on the motherboard.
The addressable RGB LED strip will only light up when the system is powered on. The addressable RGB LED strip is purchased separately.
1-16
Chapter 1: P

TomBerry

TomBerry

Bright Spark
Alright I’ve plugged in my new fan on the back, put it into the power thing for it at the bottom. How do I get the RGB lights to light up as there’s nothing else I need to plug in?

Remote for controls are working as when I press a button it lights up on the remote, but does nothing to the fan

Photo shows the controller box at the bottom and the new fan


Attachments

  • D3B10258-6BB6-4163-9E05-ECBF659636E3.jpeg
    347.5 KB · Views: 202
TomBerry

TomBerry

Bright Spark
@SpyderTracks Will you have any idea? Power box thing has connected to a SATA cable to the PSU, and then the fan connects to the box. Fan is spinning, just not getting any lighting from it

TomBerry

TomBerry

Bright Spark
Attached here, only using 1 fan so I don’t think plugging into the wrong connector would make a difference?


Attachments

  • CBA3328A-0B44-4F60-BEFF-6155E8341E51.jpeg
    375.4 KB · Views: 232
  • D27E3316-B196-4390-8179-9D56376C67F5.jpeg
    369.6 KB · Views: 209
  • 0CF4BE85-65A9-4178-A79A-669C22CA6C92.jpeg
    422.5 KB · Views: 210
SpyderTracks

SpyderTracks

We love you Ukraine
TomBerry said:
Attached here, only using 1 fan so I don’t think plugging into the wrong connector would make a difference?
Click to expand...
So it specifically says they need to be connected in the right order so from 1 upwards, so guessing it has to be in number 1?

TomBerry

TomBerry

Bright Spark
SpyderTracks said:
So it specifically says they need to be connected in the right order so from 1 upwards, so guessing it has to be in number 1?
Click to expand...
Damn it I've got it in slot 3, not slot 1...opposite end. Didn't think this would make a difference with lighting if it's only one fan connected. Will get it switched over on my 11pm break lmao thanks

I'm so bloody stupid

SpyderTracks

SpyderTracks

We love you Ukraine
TomBerry said:
Damn it I've got it in slot 3, not slot 1...opposite end. Didn't think this would make a difference with lighting if it's only one fan connected. Will get it switched over on my 11pm break lmao thanks

I'm so bloody stupid
Click to expand...
My guess is it’s a parallel circuit, so if 1 isn’t populated, it doesn’t complete the circuit to 2 and so on.
